Allen-Bradley 2098-DSD-005X-DN AC Drive

AVAILABILITY: Generally allow 7-10 days to ship



Description

Allen-Bradley 2098-DSD-005X-DN AC Drive

  • Extended Product Type: AC Drive
  • Product ID : 2098-DSD-005X-DN
  • Allen-Bradley Type Designation: AC Drive

Description of Allen-Bradley 2098-DSD-005X-DN AC Drive

The Allen-Bradley/Rockwell Automation 2098-DSD-005X-DN drive is an industrial digital servo drive. It has been designed and manufactured as part of the Allen-Bradley Ultra 3000-5000 drive series. The 2098-DSD-005X-DN digital servo drive communicates with other devices through the DeviceNet network and it connects to DeviceNet interfaces through the designated DeviceNet connector on its front panel. Its operating temperature range is from 32 to 131 degrees Fahrenheit and its storage temperature range is from -40 to 158 degrees Fahrenheit. The 2098-DSD-005X-DN digital servo drive operates with 100 to 240 Volts AC RMS single-phase input voltage.

Specifications of Allen-Bradley 2098-DSD-005X-DN AC Drive

  • Brand : Allen-Bradley
  • Series : 2098
  • Output Current (Intermittent) : 7.5 Amps (0-peak)
  • Output Current (Continuous) : 2.5 Amps (0-peak)
  • Auxiliary Power Supply : No
  • Nominal Input Current (AC) : 5 Amps Root Means Square
  • Input Frequency (AC) : 47-63 Hz
  • Input Voltage (AC) : 100-240 Voltage Root Means Square (Single Phase)
  • Bus Overvoltage : 400 Volts dc
  • Dimensions : 7.8 x 5.68 x in (198.12 x 144.27 x mm)

The Allen-Bradley 2098-DSD-005X-DN is an Ultra 3000 Digital Servo Drive Module (with DeviceNet and Indexing). This module is a single-phase AC drive used for control of most industrial servo motors. The 2098-DSD-005X-DN has an input voltage range between 100 and 240V AC at an input frequency of 47-63 Hertz. This module has a nominal input current of 5A with a current surge of 100A. The Bus overvoltage of this module is 400V DC. This module has a power output of 0.5 kW at 230V AC and an Energy Absorption Capacity of 38 J also at 230V AC.

The Allen-Bradley 2098-DSD-005X-DN has dimensions of 98.1 mm x 32.77 mm x 65.02 mm and weighs approximately 1.8 kg (4.1 lbs). The operating temperature of this module is 0-55 °C (32-131 °F). The storage temperature of this module is -40-70 °C (-40-158 °F). The relative humidity of this module is from 5-95% without condensation. The 2098-DSD-005X-DN has an operating shock of 15 g (3 pulses, 11 ms). The nonoperating shock of this module is 30 g (3 pulses, 11 ms). The 2098-DSD-005X-DN also follow some Electromagnetic Compatibility (EMC) standards. The 2098-DSD-005X-DN has passed EN 50081-2 EMC – Generic Emission Standard, Part 2 – Industrial Environment. This module has passed EN 50082-2 EMC – Generic Immunity Standard, Part 2 – Industrial Environment. If you are connecting or disconnecting the cable with power applied to this module or any device on the network, the electric arc can occur.
