Allen-Bradley 2098-DSD-HV220-DN AC Drive

• Brand : Allen-Bradley
• Series : 2098
• Product Type : Digital Servo Drive
• Continuous Output Current : 47 A
• Continuous Power Output : 11 kW
• AC Input Voltage : 230-480V AC
• AC Input Frequency :  47-63 Hz
• Main AC Input Current : 28 A
• Bus Overvoltage : 810V DC
• Shunt On : 800V DC

The 2098-DSD-HV220-DN servo drive is a digital servo drive which is an electronic amplifying device which can power modern electric servo motors. It works on the feedback signal that is received from the motor and adjusts for deviation from expected behavior. The 2098-DSD-HV220-DN servo drive is an Allen-Bradley drive from the Ultra 3000 series. The drive is equipped with the DeviceNet network for internal communication. The DeviceNet network features an automatic device replacement feature. This feature saves significant time and effort when replacing a drive. It allows the scanner to be configured to automatically detect a new drive and download the necessary parameter settings. The 2098-DSD-HV220-DN servo drive is mainly used in controlling industrial servo motors. The drive consists of 1 motor cable and 1 feedback cable. It comes with 2 SERCOS fiber optic cables for transmission. The Logix platform in the drive is used for all the control mechanisms. The motor feedback is passed on the Logix platform via the SERCOS fiber optic cables.

The 2098-DSD-HV220-DN servo drive runs with an input voltage range between 230 and 480 Volts AC with a running frequency of 47 to 63 Hertz. The rated continuous power output of the drive is 11 kilowatts. With an 800 Volts DC shunt voltage powered on, the drive has the ability to generate a continuous output current of 47 Amps. The main AC input current applied to the drive is 28 Amps. The 2098-DSD-HV220-DN servo drive can only be used within a temperature range of 0 and 55 degrees Celsius. The installation area of the drive should be free of dust and dirt and no traces of electromagnetic noise should be present. Heat generating devices should be kept far away from the digital servo drive. Starting on the installation date,
