Allen-Bradley 2098-IPD-HV150 AC Drive
- Extended Product Type: AC Drive
- Product ID : 2098-IPD-HV150
- Allen-Bradley Type Designation: AC Drive
Description of Allen-Bradley 2098-IPD-HV150 AC Drive
Specifications of Allen-Bradley 2098-IPD-HV150 AC Drive
- Brand : Allen-Bradley
- Series : 2098
- Output Current (Intermittent) : 150 Amps (0-peak)
- Output Current (Continuous) : 34 Amps (0-peak)
- Auxiliary Power Supply : Yes
- Nominal Input Current (AC) : 20 Amps Root Means Square
- Input Frequency (AC) : 47-63 Hz
- Input Voltage (AC) : 230-480 Voltage Root Means Square (Three Phase)
- Bus Overvoltage : N/A
- Shunt On : N/A
- Dimensions : 6.97 x 14.20 x 13.05 in (177.0 x 360.7 x 331.5)
The Allen-Bradley 2098-IPD-HV150 Ultra5000 is an intelligent positioning drive that can function at a temperature as low as 32 oF and at one as high as 131 oF, its storage temperature range runs from -40-185 oF, and it can tolerate ambient humidity between about 5 and 95% without condensation. It can be mounted at up to 5000 feet and still operate normally, but its functions will derate by about 3% for every 984 feet of additional altitude. When in use, the 2098-IPD-HV150 can take 2 g of vibration at 10-2000 Hz, and when not in use, it can take a shock of 15 g.
The 2098-IPD-HV150 is UL-certified for use in the US and Canada. It must have a properly-sized enclosure to provide adequate ventilation for its heat loss, which amounts to about half of its power loss (350 Watts + dissipative shunt). The 2098-IPD-HV150 drive can be used with Allen-Bradley’s 900-Watt 2090 Passive Shunt Module.
The 2098-IPD-HV150 can run on an auxiliary power supply. It absorbs 117 joules of energy when running on 230V AC with a 230V motor, it absorbs 1034 joules at 230V AC with a 460V motor, and it absorbs 439 joules at 460V AC with any motor.
The Allen-Bradley 2098-IPD-HV150 is a strong positioning drive with a 3-phase AC input voltage of 230-480 Volts Root Means Square (RMS), at an input frequency of 47-63 Hertz, and at a nominal input current of 20 Amps RMS. It also has a healthy 34 Amp (0-peak) continuous output current and it has a 150 Amps (0-peak) intermittent output current, all contained in its convenient 6.97 x 14.20 x 13.05 in. dimensions.
