Mitsubishi MR-J4-100A-KS AC Motion Servo Drive MRJ4100AKS
$2,780.00
AVAILABILITY: Generally allow 7-10 days to ship
10 in stock
Description
Mitsubishi MR-J4-100A-KS AC Motion Servo Drive MRJ4100AKS
- Extended Product Type: Motors
- Product ID: MR-J4-100A-KS
- Mitsubishi Type Designation: Motors
Description of Mitsubishi MR-J4-100A-KS Motion Servo Drive
Mitsubishi MR-J4-100A-KS AC motion servo drive / amplifier with built-in dynamic brake + built-in regenerative resistor + safety unit compatibility – (MELSERVO J4 series) – Rated output 1000W / 1kW – Rated current 6A – Supply voltage 200Vac-240Vac (200V class; 220Vac / 230Vac) / 283Vdc-340Vdc (Single-phase input (2P) or 3-phase input (3P) or DC input) – with RS-422 / RS-485 communication capability – IP20 – rated for 0…+55°C ambient – equivalent to MRJ4100AKS
Specifications of Mitsubishi MR-J4-100A-KS AC Motion Servo Drive
- Primary brand: Mitsubishi Electric
- Main function: AC servo drive
- Product series / family name: MELSERVO J4 series
- Sub-range name: MR-J4 series
- Functions: AC motion servo drive / amplifier
- positioning mode: sine wave PWM control/current control method, point table method, Indexer (turret) method, program method, 2-channel analog monitor, Safe torque off (STO), fully closed loop control, load-side encoder interface, speed control mode, torque control mode, advanced vibration suppression control II, adaptive filter II, robust filter, auto tuning, one-touch tuning, tough drive function, drive recorder function, machine diagnosis function, power monitoring function, super trace control, lost motion compensation
- Design: built-in dynamic brake, built-in regenerative resistor
- safety unit compatibility: 2-wire or 4-wire type communication method, forced ventilation cooling
- Supply voltage (AC): 200Vac-240Vac (200V class; 220Vac / 230Vac)
- Supply voltage (DC): 283Vdc-340Vdc
- Type of network: Single-phase input (2P) or 3-phase input (3P) or DC input
- Rated current: 6A
- Rated active power (kW): 1000W / 1kW
- Protection functions: overcurrent shut-off, regenerative overvoltage shut-off, overload shut-off (electronic thermal), servo motor overheat protection, encoder fault protection, regenerative fault protection, under-voltage protection, instantaneous power failure protection, overspeed protection, excessive error protection, magnetic pole detection protection, linear servo control fault protection
- Communication protocol: RS-422, RS-485
- Net Height (mm): 168 mm
- Net Width (mm): 60 mm
- Net Depth (mm): 185 mm
- Digital inputs: 1 x digital input (24Vdc; sink/source) (EM2)
- 1 x digital input (24Vdc; sink/source) (LSP)
- 1 x digital input (24Vdc; sink/source) (LSN)
- 1 x digital input (24Vdc; sink/source) (SON)
- 1 x digital input (24Vdc; sink/source) (RES)
- 1 x digital input (24Vdc; sink/source) (PC / ST1 / RS2)
- 1 x digital input (24Vdc; sink/source) (TL / ST2 / RS1)
- 1 x digital input (24Vdc; sink/source) (SP1)
- 1 x digital input (24Vdc; sink/source) (SP2)
- Digital outputs: 1 x digital output (rly. contact type) (ALM)
- 1 x digital output (rly. contact type) (ZSP)
- 1 x digital output (rly. contact type) (TLC / VLC)
- 1 x digital output (rly. contact type) (INP / SA)
- 1 x digital output (rly. contact type) (RD)
- Analog inputs: 1 x analog input (0-10Vdc) (TLA / TC)
- 1 x analog input (-10…+10Vdc) (VC / VLA)
- Analog outputs: 1 x analog output (-10…+10Vdc) (MO1)
- 1 x analog output (-10…+10Vdc) (MO2)
- Degree of protection: IP20
- Dimensions: H168mm x W60mm x D185mm
- Ambient air temperature for operation: 0…+55 °C
- Ambient air temperature for storage: -20°C…+65 °C
- Current consumption: 5A input
- Power consumption: (drive auxiliary power consumption) 30 W
- Equivalent to: MRJ4100AKS
- Order code / Manufacturer SKU: MR-J4-100A-KS
- Compliant with standard(s): CE marking, TUV Rheinland, cULus, UL, KC, EN61800-5-2, EN61800-5-1, EN61800-3, EN ISO 13849-1 PLe Cat3, EN62061, SILCL3, IEC61508-5-2, EN50581, UL508C, CSA, KC, EAC
- Benefits: high-speed serial communication, A/B/Z-phase differential input signal
- Compatible with servo motors: HG-JR53 (3A), HG-SR81 (5.2A), HG-SR102 (5.6A), HG-JR103 (5.6A), TM-RFM018E20 (6A)
Additional information
| Weight | 5 lbs |
|---|---|
| Dimensions | 6 × 5 × 8 in |
