Description

Mitsubishi Q62DA-FG Analog Output Module Q62DAFG Code: 1W4571

Model Code: 1W4571

2 channels, input (resolution): 0…12000, -12000…12000, -16000…16000, output: -12…12 V DC, 0…22 mA
DC, conversion speed: 10 ms/2 channels, 18-point terminal block, channel isolated

This analogue output module is used to convert digital values predetermined by the CPU into an analogue current or voltage signal, e.g. frequency inverters, valves or slide valves.

Features of Mitsubishi Q62DA-FG Digital-Analog Output Module

• Resolution of 0.333mV and 0.83 μA
• Conversion time of 80 μs/channel
• Removable terminal block fastened with screws
