Omron PLC Input Module CJ1W-ID211

Description

Omron PLC Input Module CJ1W-ID211

• Extended Product Type: CJ1W

• Product ID: CJ1W-ID211

• OMRON Type Designation : CJ1W

• Description: INPUT MODULE 16 DIGITAL

Features

• High-speed input models are available, meeting versatile applications.
ON Response Time: 15μs, OFF Response Time: 90μs
• Use 24-VDC, 100-VAC, and 200-VAC models to connect to devices with different types of outputs.
• The 24-VDC models can be connected to devices with either NPN or PNP outputs. There is no need to select the polarity. *1
• A digital filter in the Unit can be set from 0 to 32 ms to reduce the influence of external noise.
• Either a Fujitsu or MIL connector interface can be used. *2
• Several models of Terminal Block Conversion Units are available, making it easy to connect to external devices.
*1. The same polarity is used for the same common.
*2. For models with 32 or 64 inputs.

International Standards

• The standards are abbreviated as follows: U: UL, U1: UL (Class I Division 2 Products for Hazardous Locations), C: CSA, UC: cULus,
UC1: cULus (Class I Division 2 Products for Hazardous Locations), CU: cUL, N: NK, L: Lloyd, and CE: EC Directives.
• Contact your OMRON representative for further details and applicable conditions for these standards.

Specification

• I/O points : 16 inputs
• Input voltage and current : 24 VDC, 7 mA
• Internal Current Consumption : 80 mA max
• Weight : 110 g max.
• Standards : UC1, N, L, CE
