Description

Schneider ATS480C17Y Soft Starter Asynchronous Motor 45kW 170A

• Extended Product Type: Motors
• Product ID: ATS480C17Y
• Schneider Type Designation: Motors

Description of Schneider ATS480C17Y Soft Starter Motor 45kW

This Schneider ATS480C17Y Altivar Soft Starter ATS480 is intended to start and stop asynchronous motors supplied from 208V to 690V. It meets the requirements of the most demanding applications in normal and heavy duty. With an operational rated current of 170A in normal duty, it supplies motor from 45kW to 160kW according to mains voltage. Designed for digitization, connected, optimized to meet cybersecurity standard, it simplifies project execution and maximizes the availability of applications. Its torque control (TCS) masters acceleration and deceleration. It efficiently stops high inertia application thanks to the dynamic braking and DC injection. It could be connected in-line or inside the delta to reduce its operational current. The embedded test routine simplifies the commissioning inside the delta. Its dimensions are 200mm (width) x 272mm (depth) x 340mm (height) and it weighs 12,4kg. Altivar Soft Starter ATS480 is designed to address process, infrastructures and industrial machines. It conforms to IEC/EN60947-4-1. It is certified CE, cULus, UKCA, CCC, RCM, EAC, and Marine certified DNV, ABS, BV and CCS. Display terminals, remote mounting kit, communication modules are common with Altivar Drives. Line chokes, DNV kits are common with ATS48. ATS480 is compatible with ATS48, it has same footprint, fixing, torque control algorithm, I/O, menus… The integration of Altivar Soft Starter ATS480 in EcoStruxure drastically simplifies architecture selection, detailed design and execution in automation and electrical systems. It is a Green Premium product designed to take the environmental considerations beyond current directives and regulations, compliant with RoHS and REACH.

Specifications of Schneider ATS480C17Y Soft Starter Motor 45kW 170A

• Range of product: Altivar Soft Starter ATS480
• product or component type: Soft starter
• product destination: Asynchronous motors
• Product specific application: Process and infrastructures
• Device short name: ATS480
• Network number of phases: 3 phases
• Utilisation category: AC-3A, AC-53A
• Ue power supply voltage: 208…690 V – 15…10 %
• power supply frequency: 50…60 Hz – 20…20 %
• [Ie] rated operational current: Normal duty: 17.0 A (at <40 °C)
• rated current in heavy duty: 12.0 A at 40 °C for heavy duty
• Torque control: True
• IP degree of protection: IP20
• Motor power kW: 45.0 kW 230 V in the motor supply line normal duty
  • 37.0 kW 230 V in the motor supply line heavy duty
  • 90.0 kW 400 V in the motor supply line normal duty
  • 75.0 kW 400 V in the motor supply line heavy duty
  • 90.0 kW 440 V in the motor supply line normal duty
  • 75.0 kW 440 V in the motor supply line heavy duty
  • 110.0 kW 500 V in the motor supply line normal duty
  • 90.0 kW 500 V in the motor supply line heavy duty
  • 110.0 kW 525 V in the motor supply line normal duty
  • 90.0 kW 525 V in the motor supply line heavy duty
  • 132.0 kW 660 V in the motor supply line normal duty
  • 110.0 kW 660 V in the motor supply line heavy duty
  • 160.0 kW 690 V in the motor supply line normal duty
  • 110.0 kW 690 V in the motor supply line heavy duty
  • 90.0 kW 230 V to the motor delta terminals normal duty
  • 75.0 kW 230 V to the motor delta terminals heavy duty
  • 132.0 kW 400 V to the motor delta terminals normal duty
  • 110.0 kW 400 V to the motor delta terminals heavy duty
• Maximum Horse Power Rating: 50.0 hp 208 V normal duty
  • 40.0 hp 208 V heavy duty
  • 60.0 hp 230 V normal duty
  • 50.0 hp 230 V heavy duty
  • 125.0 hp 460 V normal duty
  • 100.0 hp 460 V heavy duty
  • 150.0 hp 575 V normal duty
  • 125.0 hp 575 V heavy duty
• Option card: Communication module for Profibus DP V1
  • Communication module for PROFINET
  • Communication module for Modbus TCP/EtherNet/IP
  • Communication module for CANopen daisy chain
  • Communication module for CANopen Sub-D
  • Communication module for CANopen open style
