Mitsubishi TM-RFM120J10 DD Rotary Servo Motor TMRFM120J10

$35,000.00

AVAILABILITY: Generally allow 7-10 days to ship

Mitsubishi TM-RFM120J10 High-rigidity direct-drive. (DD) rotary servo motor with hollow flanged shaft + built-in thermistor + built-in absolute feedback encode (20-bit) – Mitsubishi Electric (MELSERVO J4 – TM-RF series) – Rated output 1257W / 1.257kW – 20-bit (equivalent to 1048576 ppr) feedback – Rated current 11A – Rated torque 120Nm nominal – Rated rotational speed 100rpm – 330x330mm flange mounting – IP42 – rated for 0…+40°C ambient – equivalent to TMRFM120J10

SKU: TM-RFM120J10 Category: Tag: Brand:
  • Same-day shipping on in-stock items ordered by 4:00 PM Eastern
  • 1-year warranty on most products

Description

Mitsubishi TM-RFM120J10 DD Rotary Servo Motor TMRFM120J10

  • Extended Product  Type: Servo Motor
  • Product ID: TM-RFM120J10
  • Mitsubishi Type Designation: Servo Motor

Definition of Mitsubishi TM-RFM120J10 DD Rotary Servo Motor

Mitsubishi TM-RFM120J10 High-rigidity direct-drive. (DD) rotary servo motor with hollow flanged shaft + built-in thermistor + built-in absolute feedback encode (20-bit) – Mitsubishi Electric (MELSERVO J4 – TM-RF series) – Rated output 1257W / 1.257kW – 20-bit (equivalent to 1048576 ppr) feedback – Rated current 11A – Rated torque 120Nm nominal – Rated rotational speed 100rpm – 330x330mm flange mounting – IP42 – rated for 0…+40°C ambient – equivalent to TMRFM120J10

Specification of Mitsubishi TM-RFM120J10 DD Rotary Servo Motor

  • Primary brand: Mitsubishi Electric
  • Main function: AC servo motor
  • Product series/family name: Industrial automation > Drive products > Servo systems > AC Servo motors > MELSERVO J4 series
  • Sub-range name: MELSERVO J4 – TM-RF series
  • Functions: High-rigidity direct-drv. (DD) rotary servo motor
  • Design: hollow flanged shaft, built-in thermistor, built-in absolute feedback encod. (20-bit), high-rigidity, natural cooling
  • Rated current: 11A, 33A (max. current)
  • Rated active power (kW): 1257W / 1.257kW
  • Rotational speed: 100rpm, 200rpm (maximum)
  • Torque: 120Nm nominal
  • Maximum torque: 360Nm
  • Moment of inertia: 0.3519kg.m2 (3519kg.cm2)
  • Mounting mode: 330x330mm flange mounting
  • Resolution: 20-bit (equivalent to 1048576 ppr) feedback
  • Degree of protection: IP42
  • Ambient air temperature for operation: 0…+40 °C
  • Ambient air temperature for storage: -15°C…+70 °C
  • Maximum axial load: 16000 N
  • Order code/Manufacturer SKU: TM-RFM120J10
  • Manufacturer product status: Commercialized
  • Equivalent to: TMRFM120J10
  • Manufacturer description: DDM SRVMTR 1257W 120NM RATED
  • Compliant with standard(s): CE marking, TUV Rheinland, cULus, UL, KC, EN61800-3, EN60034-1, EN62061, SILCL3, EN50581, UL1004-1, UL1004-6, CSA, KC, EAC
Recommended accessories: for standard 1-axis use amplifiers – MR-J4-500GF – MR-J4-500GF-RJ – MR-J4-500B – MR-J4-500B-RJ – MR-J4-500A – MR-J4-500A-RJ Use amplifier <=> motor cables as follows

Additional information

Weight 40 lbs
Dimensions 18 × 18 × 20 in
